SAILOR 6080 AC/DC Power Supply 300W/28V DC
SAILOR 6080 AC/DC Power Supply 300W/28V DC
Cobham Sailor
SKU:406080A-00501
Regular price
€860,00
Regular price
Sale price
€860,00
Unit price
/
per
SAILOR 6080 AC/DC Power Supply 300W/28V DC
- Description
SAILOR 6080 AC/DC Power Supply 300W/28V DC
Product available
Status: On order
Couldn't load pickup availability
Please note: Where product price is not shown, you can request for quote to receive information on availability and pricing. Product price will appear €0,00 in cart and checkout. A quote is non-binding.
Share
Thrane & Thrane has ventured into a modular design set-up for a Power Supply Unit, with great benefits including greater flexibility and easier installation than ever seen before. The new power supply also features AC alarm and automatic input range selections.
The SAILOR 6080 Power Supply can deliver 300 W output power on average with a peak of 370 W for a minimum of 2 minutes. It is AC powered.
- IEC 60945 Maritime approval
- Two DC connectors, output, range: 28.7 V - 31.2 V
- Output power 300 W continuous, 370 W peak (2 min., 100-240 VAC) or 270 W continuous, 333 W peak (2 min., 90-100 VAC)
- AC input (100-240 VAC operating) with fuse (6.3 A)
- Automatic selection of input voltage range
- AC alarm and On/off switch
- Daisy-chaining of up to three units to give up to 900 W.1
- Short circuit protection
- Over-temperature protection (shutdown with automatic restart)
- Battery switch-over in case of AC supply failure, secured by 2 fuses (30 A)
- No forced cooling required
- IP 3X for internal high voltage areas (>42 V), IP 2X in other areas
- IP X2 when vertically mounted (wall) and connector panel is facing down
